Hydraulic Monoblock Solenoid Control Valve, 3 Spool, 13 GPM, 12V DC. Hydraulic Monoblock Valves are a style of Hydraulic Control valve. These valves are used to start and stop fluid flow into hydraulic motors. The number of motors that a control valve can operate is dependent on the number of spools on a valve. The flow rate listed is the maximum allowed GPM (Gallons Per Minute) that can be put through a valve. A common example of a hydraulic control valve is the loader valve on a tractor. Our monoblock valves have power beyond Capability (Power Beyond Adapter Sleeve is required SKU: P40-PB), as well as the ability to operate as a closed-center valve (Closed-Center Plug Required SKU: P40-CC). Operate hydraulic motors (“D” Spool Required): Brush Cutter, Snow Blower. D Spool (Motor Control). All spools are double acting with spring return to neutral position, D spool is designed for non-load holding applications such as motors and horizontal cylinders. A and B ports are open to Tank in neutral position. Precision ground and hard chrome-plated spools assure a long life. High-tensile strength cast iron monoblock construction. SAE O-Ring ports ensure solid seal and prevent blockages. Used for open center systems (Pump to Tank Flow). Capable of closed center or Power Beyond. Adjustable Relief Valve Range: 1500 to 3625 PSI. 12 Volt DC Solenoids. DIN 43650 3 Prong Connectors. Max Operating Pressure: P = 3625 PSI, T = 725 PSI, A & B = 4350 PSI. Preset Pressure Relief: 2610 PSI. A & B Work Ports: #8 SAE O-Ring (3/4-16) Thread. Inlet Port: #10 SAE O-Ring (7/8-14) Thread. Outlet Port: #10 SAE O-Ring (7/8-14) Thread. Nominal Voltage Tolerance +/- 10%. Will this valve work for my application? You’ll need to answer the following questions. Is the flow through this valve less than 13 GPM? If not, then we have larger Z80 valves that can accommodate up to 21 GPM, and Z100 Valves if the flow is between 21 GPM and 27 GPM. If installing on a tractor please check tractor-data. Com, it will say under the hydraulics – “Pump Flow” – of the data sheet. The GPM flow may be printed on the pump itself. Do you have an open-center hydraulic system? If you’re installing this on a tractor please check tactor-data. Com, it will say under the hydraulics of the data sheet. These valves are setup for use on open-center hydraulic systems. If you do have a closed-center system you’ll need to get the closed center adapter sleeve. NOTE: None of our valves have load-sensing capabilities. Do you have other valves downstream from this valve (Examples include: Other Control Valves, Rear Remote Valve, Backhoe Valve, 3-Point Valve)? If so, you’ll need the power beyond adapter sleeve to provide pressure and flow to those valves. Note: This is only needed on open-center hydraulic systems. If you have a closed-center system, you will tee into a pressure line to connect other valves. Are you operating a hydraulic cylinder or a hydraulic motor? If you’re operating a hydraulic motor, this valve will work for you. Note: “D” spools cannot be used for operating hydraulic cylinders and “A” spools cannot be used to operate hydraulic motors. 13 GPM Solenoid Directional Control Valves. Hydraulic Monoblock Solenoid Directional Control Valve, 1 Spool. Hydraulic Monoblock Solenoid Directional Control Valve, 2 Spool. Hydraulic Monoblock Solenoid Directional Control Valve. Hydraulic Monoblock Solenoid Motor Control Valve. 21 GPM Solenoid Directional Control Valve. Hydraulic Monoblock Solenoid Directional Control Valve, 5 Spool. Hydraulic Monoblock Solenoid Motor Control Valve, 1 Spool. Hydraulic Monoblock Solenoid Motor Control Valve, 2 Spool. Hydraulic Monoblock Solenoid Motor Control Valve, 4 Spool. Hydraulic Monoblock Solenoid Motor Control Valve, 5 Spool. 27 GPM Solenoid Directional Control Valve. Power Beyond Adapter Sleeve for P40 Series Monoblock Valves. Closed Center Adapter Plug for P40 Series Monoblock Valves. Power Beyond Adapter Sleeve for P80 Series Monoblock Valves. Closed Center Adapter Plug for P80 Series Monoblock Valves. We got you covered! Are you looking for high quality, durable hydraulic valves and quick couplers you can depend on? Do you want a supplier that values you as a customer and stands behind their product? Choose Summit Hydraulics today and choose a leader in hydraulic couplers and valves. Summit Hydraulics specializes in and offers a wide range of quality, durable hydraulic couplers and valves to the construction, agricultural and forestry industries. Our various lines of quick couplers and hydraulic valves are chosen by many companies around the world for our high quality standards and competitive prices. The Summit Hydraulics Mission. Serving the construction and agriculture industry needs around the world, Summit Hydraulics is a family owned and operated company focused on quality products, exceptional service and competitive prices. As one of the leading online suppliers of hydraulic valves and quick couplers, we have made it our mission to continue designing and developing new products that meet our customers’ needs for quality, durability and value. Why Choose Summit Hydraulics? Summit Hydraulics offers quality products at competitive prices. All of our manufacturing partners are ISO 9001 certified to help ensure all of our products built to strict manufacturing quality standards. Summit Hydraulics values our customers and works hard to ensure complete satisfaction. Before, during and after every sale, we will be there to answer your questions and provide the best experience possible. Our operating hours are Monday-Friday 08:00 A. To 4:00 P. Unsure where your order is? We have high standards when it comes to packaging your order. However, mistakes do happen. Please accept our apologies if you have received an incorrect, defective or damaged item. It will walk you through the steps afterwards. 21415 N 15th lane.
