NOTE: We issue VAT invoices for countries in the European Union. Hand control valve Hand lever valve hydraulic 40L / min 2-fold for 1x double-acting cylinder. Controlled with the Bowden cables. It is widely used in hydraulic systems in agriculture, horticulture, forestry, construction, and broader industry. The distributor is adapted to different types of machines, such as B. Agricultural machines, tractors, sprayers, round vehicles, cyclo-loaders, HDS loaders, construction machinery, loaders, excavators, sweepers, industrial machines and other hydraulically controlled devices. Recommended system oil flow: 0 – 40 l / min. Example control: 2-sided drive. Can be connected in series to an existing system (pressure sleeve required). Three-position lever (1 – 0 – 2), spring-loaded, ie it moves back into the vertical position. Neutral position 0 (lever up), piston rod of the hydraulic cylinder is stationary – oil overflows. Working position 1 (lever up), the piston rod of the hydraulic cylinder slides out. Working position 2 (lever up), the piston rod of the hydraulic cylinder retracts. Four-position lever (1 – 0 – 2 – 3), three positions (1 – 0 – 2) on spring (lever goes back to vertical position), position (3) on spring clip (lever stops in floating position). Position 0 neutral (lever in vertical position) The actuator piston rod is stationary – oil overflows. Position 1 (lever in front inclined position) The cylinder piston rod slides out. Position 2 (lever in diagonal reverse position) the piston rod retracts. Position 3 floating with latch (lever in maximum forward position) The piston rod loosens, pulls out and moves in freely under the action of force. Pump supply (P): female thread BSP 1/2′. Return to tank (T): female thread BSP 1/2. Output for sections (A, B): Female thread BSP 3/8. Series connection (N): Female thread BSP 1/2. Maximum inlet pressure: 250bar Maximum return pressure: 50bar Maximum pressure on sections: 300bar. Factory-set overflow valve to 175 bar Self-adjusting, full turn, change by 30 bar. Wide lever configuration options (examples in picture). Recommended oil temperature range. Permissible ambient temperature: -40 ° C to +60 ° C Permissible oil temperature: -15 ° C to +80 ° C.
