Monoblock Hydraulic Directional Control Valve, 4 Spool, 4 Float, 11 GPM. This monoblock valve is a hydraulic directional control valve. These valves are used to start and stop fluid flow into hydraulic cylinders or hydraulic motors. Operate hydraulic cylinders (Double-Acting or Single-Acting). Operate hydraulic motors (“D” Spool Required). Install rear remotes on a tractor. 4 Spool valve with compact design allows for installations in tight areas. All spools lock into forward position detent to allow for float. Used for open center systems (Pump to Tank Flow). Anti-drop load checks on each spool. Precision ground and hard chrome-plated spools assure a long life. High-tensile strength cast iron monoblock construction. SAE O-Ring ports ensure solid seal and prevent blockages. Vertical or horizontal handle mount. Adjustable Relief Valve Range: 1500 to 3625 PSI. Used as motor or single-acting spool possible (#8 SAE port plug required). Max Operating Pressure: P = 3625 PSI, T = 725 PSI, A & B = 4350 PSI. Preset Pressure Relief: 2610 PSI. A & B Work Ports: #8 SAE O-Ring (3/4-16) Thread. Inlet Port: #10 SAE O-Ring (7/8-14) Thread. Outlet Port: #10 SAE O-Ring (7/8-14) Thread. 2 – 5/16 Mounting Holes. Will this valve work for my application? You’ll need to answer the following questions. Is the flow through this valve less than 11 GPM? If not, then we have larger P80 valves that can accommodate up to 21 GPM. If installing on a tractor please check online for your “Pump Flow”. The GPM flow may be printed on the pump itself. Do you have an open-center hydraulic system? If you’re installing this on a tractor please check online. These valves are setup for use on open-center hydraulic systems. If you do have a closed-center system you’ll need to get the. Closed center adapter plug. NOTE : None of our valves have load-sensing capabilities. Do you have other valves downstream from this valve (Examples include: Other Control Valves, Rear Remote Valve, Backhoe Valve, 3-Point Valve)? If so, you’ll need the. Power beyond adapter sleeve. To provide pressure and flow to those valves. Note : This is only needed on open-center hydraulic systems. If you have a closed-center system, you will tee into a pressure line to connect other valves. Are you operating a hydraulic cylinder or a hydraulic motor? If you’re operating a hydraulic cylinder you’ll need to get “A” spools for double acting cylinders, if you’re operating a hydraulic motor you’ll need “D” spools for motor control. Note : “D” spools cannot be used for operating hydraulic cylinders and “A” spools cannot be used to operate hydraulic motors. How do I connect this valve to my hydraulic system? This valve has a pressure line (Inlet), tank line (outlet), work ports (A/B ports that go to hydraulic cylinder or motor), and optional power beyond port (N Port, used to connect valves downstream). Some common examples of connecting this valve below, however it is possible to connect it in different configurations than shown. We got you covered! Are you looking for high quality, durable hydraulic valves and quick couplers you can depend on? Do you want a supplier that values you as a customer and stands behind their product? Choose Summit Hydraulics today and choose a leader in hydraulic couplers and valves. Summit Hydraulics specializes in and offers a wide range of quality, durable hydraulic couplers and valves to the construction, agricultural and forestry industries. Our various lines of quick couplers and hydraulic valves are chosen by many companies around the world for our high quality standards and competitive prices. The Summit Hydraulics Mission. Serving the construction and agriculture industry needs around the world, Summit Hydraulics is a family owned and operated company focused on quality products, exceptional service and competitive prices. As one of the leading online suppliers of hydraulic valves and quick couplers, we have made it our mission to continue designing and developing new products that meet our customers’ needs for quality, durability and value. Why Choose Summit Hydraulics? Summit Hydraulics offers quality products at competitive prices. All of our manufacturing partners are ISO 9001 certified to help ensure all of our products built to strict manufacturing quality standards. Summit Hydraulics values our customers and works hard to ensure complete satisfaction. Before, during and after every sale, we will be there to answer your questions and provide the best experience possible. Our operating hours are Monday-Friday 08:00 A. To 4:00 P. Unsure where your order is? We have high standards when it comes to packaging your order. However, mistakes do happen. Please accept our apologies if you have received an incorrect, defective or damaged item. It will walk you through the steps afterwards. 21415 N 15th lane.
