NOTE: We also issue VAT invoices on request. 5 Bank Hydraulic Directional Control Valves 5 x Double Acting 40L 11gpm. HYDRAULIC DISTRIBUTOR 5 SECTION P40. CONTROL BY BUILT-IN JOYSTICKx2. Symbol: 05P40 5xA1+ 2x JOY. It is widely used in hydraulic systems in agriculture, horticulture, forestry, construction, and well-known industries. The distributor is adapted to different types of machines, such as B. Agricultural machines, tractors, sprayers, round vehicles, cyclo-loaders, HDS loaders, construction machinery, loaders, excavators, sweepers, industrial machines and other hydraulically controlled devices. Recommended oil flow: 0 – 40 l / min. Example control: two 2-way drives. Possibility of serial connection to the existing system (pressure sleeve required). Joystick with five positions (1 – 2 – 0 – 3 – 4) on the spring, i. Position 0 neutral (joystick positioned vertically) piston rods of both drives are stationary – oil overflows. Working position 1 (joystick lever tilted forward) The piston rod of the first actuator extends. Working position 2 (joystick lever in an inclined position) The piston rod of the first drive is retracted. Working position 3 (joystick lever inclined to the left) The piston rod of the other drive extends. Working position 4 (joystick lever inclined to the right) The piston rod of the other drive is retracted. Pump supply (P1, P2): BSP 1/2 internal thread. Back to the tank (T1, T2): BSP 1/2 internal thread. Sections (A1, A2; B1, B2): BSP 3/8 internal thread. Serial connection (N): BSP 1/2 internal thread. Maximum pressure on the supply: 250bar. Maximum return pressure: 50 bar. Maximum pressure on the sections: 300 bar. The overflow valve is factory-set to 175 bar. Possibility of self-regulation, full turnover change by 30bar.

Comments Off

NOTE: We issue VAT invoices for countries in the European Union. HYDRAULIC DISTRIBUTOR 6 SECTION P80 6x Double Acting. CONTROL BY BUILT-IN 2x JOYSTICK. Symbol: 06P80 6xA1 + 2xJOY. It is widely used in hydraulic systems in agriculture, horticulture, forestry, construction, and well-known industries. The distributor is adapted to different types of machines, such as B. Agricultural machines, tractors, sprayers, round vehicles, cyclo-loaders, HDS loaders, construction machinery, loaders, excavators, sweepers, industrial machines and other hydraulically controlled devices. Recommended oil flow: 0 – 80 l / min. Example control: two 2-way drives. Possibility of serial connection to the existing system (pressure sleeve required). Joystick with five positions (1 – 2 – 0 – 3 – 4) on the spring, i. Position 0 neutral (joystick positioned vertically) piston rods of both drives are stationary – oil overflows. Working position 1 (joystick lever tilted forward) The piston rod of the first actuator extends. Working position 2 (joystick lever in an inclined position) The piston rod of the first drive is retracted. Working position 3 (joystick lever inclined to the left) The piston rod of the other drive extends. Working position 4 (joystick lever inclined to the right) The piston rod of the other drive is retracted. Return to the tank (T): BSPP 3/4 female thread. Outlet for section (A, B): BSPP 1/2 female thread. Series connection (N): BSPP 3/4 female thread. Maximum pressure on the supply: 250bar. Maximum return pressure: 50 bar. Maximum pressure on the sections: 300 bar. The overflow valve is factory-set to 175 bar. Possibility of self-regulation, full turnover change by 30bar. Dimensions can be changed slightly.

Comments Off

NOTE: We issue VAT invoices for countries in the European Union. HYDRAULIC DISTRIBUTOR 4 SECTION P80 4x Double Acting. CONTROL BY BUILT-IN 2x JOYSTICK. Symbol: 04P80 A1A1A1A1 + 2xJOY. It is widely used in hydraulic systems in agriculture, horticulture, forestry, construction, and well-known industries. The distributor is adapted to different types of machines, such as B. Agricultural machines, tractors, sprayers, round vehicles, cyclo-loaders, HDS loaders, construction machinery, loaders, excavators, sweepers, industrial machines and other hydraulically controlled devices. Recommended oil flow: 0 – 80 l / min. Example control: two 2-way drives. Possibility of serial connection to the existing system (pressure sleeve required). Joystick with five positions (1 – 2 – 0 – 3 – 4) on the spring, i. Position 0 neutral (joystick positioned vertically) piston rods of both drives are stationary – oil overflows. Working position 1 (joystick lever tilted forward) The piston rod of the first actuator extends. Working position 2 (joystick lever in an inclined position) The piston rod of the first drive is retracted. Working position 3 (joystick lever inclined to the left) The piston rod of the other drive extends. Working position 4 (joystick lever inclined to the right) The piston rod of the other drive is retracted. Return to the tank (T): BSPP 3/4 female thread. Outlet for section (A, B): BSPP 1/2 female thread. Series connection (N): BSPP 3/4 female thread. Maximum pressure on the supply: 250bar. Maximum return pressure: 50 bar. Maximum pressure on the sections: 300 bar. The overflow valve is factory-set to 175 bar. Possibility of self-regulation, full turnover change by 30bar. Dimensions can be changed slightly.
